Documentation and Utilities
Catalogues, Brochures, Flyers, Datasheets
Application Notes
| Doc ID | Title | Description | Version | Download |
|---|---|---|---|---|
| AN-100 | Access to Planevision Systems Internet Customer Area | Customized documentation for PlaneTRack devices is accessible via a closed internet customer web area. | 1.1 |  |
| AN-101 | PlaneTRack data output of Eurocontrol Asterix formats CAT 021, CAT023, CAT247 | This Application Note describes the Asterix implementation for CAT021, CAT023 and CAT247 of PlaneTRack ADS-B/FLARM devices with Asterix Output Option enabled. For CAT 021 this document covers V0.23, V0.26, V1.8, V2.4 and FLARM data outputs. | 3.2 | |
| AN-102 | JetViewS outlines and waypoints file formats | JetViewS can display user generated waypoints and outlines. The format used is mostly compatible with the standard format wpt and out files | 1.0 | |
| AN-103 | ADSB, Mode-S and ACAS flight data analysis with “ExtFlightData” function | This Application Note describes the Extended CSV output format of PlaneTRack devices with the Extended CSV Output Option enabled. | 1.2 | |
| AN-103A | Appendix | DATA DICTIONARY for RESTFUL API (Extended CSV) format | 1.1 | |
| AN-104 | Commissioning of a PlaneTRack ADSB Receiving Station | This Application Note describes the commissioning of a PlaneTRack device, aerials, surge connectors, earth connections etc. | 1.2 | |
| AN-105 | Usage of PlaneTRack Video Outpu | This Application Note describes the usage of the Video output of Planevision Systems PlaneTRack devices. | 1.0 | |
| AN-106 | Alternate/emergency access to console | This Application Note describes the alternate/emergency console access of PlaneTRack devices. Available on request only. |  | |
| AN-109 | SNMP manager software | This Application Note describes the use of the SNMP manager software for PlaneTRack devices. | 1.0 | |
| AN-112 | Asterix overview and specifics of CAT025, CAT048, CAT181, CAT182 data output | This Application Note provides an overview about PlaneTRack Asterix implementations and describes the use of CAT025, CAT048, CAT181, CAT182. | 2.0 | |
| AN-112/025 | Asterix output format CAT025 | Data format specification | 1.0 | |
| AN-112/048 | Asterix output format CAT048 | Data format specification | 1.0 | |
| AN-112/181 | Asterix output format CAT181 | Data format specification | 1.0 | |
| AN-112/182 | Asterix output format CAT182 | Data format specification | 1.1 | |
| AN-116/6 | PlaneTRack output format 6 (Port 30003) | Output format definition | 1.0 | |
| AN-116/6-A | Analyzing Port 30003 (Format 6) CSV messages | This Application Note describes how format 6 messages can be recorded, processed and analyzed. | 1.0 | |
| AN-183 | PlaneTRack data output of NMEA-0183 formats | This Application Note describes the implementation of NMEA-0183 (IEC 61162) formatted data output of PlaneTRack ADS-B devices for use in maritime navigation systems. | 1.1 | |
| Table 6-1 | Table to Operating Manual | PlaneTRack data formats and protocols. | 1.4 | |
Software/Firmware Updates, Service Bulletins
| Doc ID | Title | Description | Version | Download |
|---|---|---|---|---|
| UP-501 | GPS firmware update for Asia area | Mandatory update required for receivers operating in the East Asia region only. This update fixes a problem of Trimble GPS modules with certain new GPS geostationary satellites in that region. It also fixes a 1024-Week-Rollover bug in certain older Trimble GPS chips. | 1.05 | |
| UP-502 | Firmware update for RESTFUL API (extended CSV) | Update for receivers suffering from system restarts when certain RESTFUL API calls are executed and responses include malformed packets from certain ADS-B transmitter equipment (non-aircraft) | 1.01 | |
| UP-503 | Google Maps (2D map) interface firmware update | Mandatory update for all receivers when the Google Maps display does not show a background map. | 1.0 | |
| UP-504 | Asterix add-on firmware update (V1.8/2.4) | Mandatory update for all receivers utilizing this add-on. This update fixes wrong packet lengths and malformed packets from reponses of certain types of airborne ADS-B equipment (MOPS 1). | 1.0 | |
| UP-505 | Jetview-S METAR/QNH display | Mandatory update for all Jetview-S installations showing METAR data. | 1.0 | |
| SB-506 | GPS Week Number Roll Over (WNRO) April 06, 2019 | For information only. | 1.0 | |
| SB-507 | Annual FLARM firmware update | Mandatory update for all Type B-FLARM ground stations. | 1.0 | |
Certificates, Operating Manuals
| Doc ID | Title | Description | Version | Download |
|---|---|---|---|---|
| OPS-1 | Operating Manual (Sample) | A sample of a PlaneTRack Operating Manual. Operating Manuals are customized upon delivery of PlaneTRack devices and are made available through the CUSTOMER AREA of this web page | 1.0 | |
| OPS-B-FLARM | B-FLARM Supplemental Operating Manual | An extension to the PlaneTRack Operating Manual for devices Type B-FLARM. | 1.3 | |
| QSM-1-B | Quick Start Leaflet (Sample) | A sample of a PlaneTRack Quick Start Instructions Leaflet for PlaneTRack Type B. These instructions are be shipped with the device | 2.0 | |
| QSM-1-B10 | Quick Start Leaflet (Sample) | A sample of a PlaneTRack Quick Start Instructions Leaflet for PlaneTRack Type B-10. These instructions are be shipped with the device | 2.0 | |
| DOC-1 | Declaration of Conformity | CE DoC for ADS-B receivers types PlaneTRack Type B / BA / BA-10 / B10 / B-AD / BDM / RDM / AS | 1.0 | |
| DOC-2 | Declaration of Conformity | CE DoC for ADS-B antennas Type SCO-1.09-5 N-f/ 10M-SMA / 3M-MCX / N-f-MO | 1.0 | |
| TR-60950 | Test report | CE Test report for EC “Low voltage directive” 2006/95/EC, according to standard EN 60950-1 “Electrical Safety”. | | |
| TR-301489 | Test report | CE Test report for EC “Radio & Telecommunications Terminal Equipment Directive” 1999/5/EC, according to standard EN 301 489 “Electromagnetic Compliance”. | | |
| TR-DO-160 | Test report | Test report according to RTCA DO-160G sections 4 (temperature, decompression), 7 (shock) and 8 (vibration). | | |
| TR-MIL-810 | Test report | Test report according to MIL-STD-810G methods 507.5 (humidity) and 509.5 (salt fog). | | |
| ISO9001 | Certificate | Certificate about the compliance of our management system with ISO9001:2015 | |
Utilities
| Filename | Description | Version | Download |
|---|---|---|---|
| pingpt.exe | A Windows utility that finds PlaneTRack devices in local networks by means of a UDP broadcast to/from port 15192. This utility is useful when a PlaneTRack device is operated as a DHCP client. Instructions: download and unpack the zip file to any place. Execute pingpt.exe. As the utility requires inbound access to UDP port 15192 the Windows inbound firewall alert must be accepted on first run. Any PlaneTRack devices found will be shown in the list. Note: on Windows PCs that have multiple network adapters active the last enumerated network environment will be searched (see bottom status line for active IP range). | 1.0.0 |  |
